Oracle



Disk files primarily represent one of the following structures:

  • Data and index files: These files provide the physical storage of data, which can consist of the data-dictionary data (associated to the tablespace SYSTEM), user data, or index data. These files can be managed manually or managed by Oracle itself ("Oracle-managed files"). Note that a datafile has to belong to exactly one tablespace, whereas a tablespace can consist of multiple datafiles and.
  • Redo log files, consisting of all changes to the database, used to recover from an instance failure. Note that often a database will store these files multiple times, for extra security in case of disk failure. The identical redo log files are said to belong to the same group.
  • Undo files: These special datafiles, which can only contain undo information, aid in recovery, rollbacks, and read-consistency.
  • Archive log files: These files, copies of the redo log files, are usually stored at different locations. They are necessary (for example) when applying changes to a standby database, or when performing recovery after a media failure. It is possible to archive to multiple locations.
  • Tempfiles: These special datafiles serve exclusively for temporary storage data (used for example for large sorts or for global temporary tables)
  • Control file, necessary for database startup. "A binary file that records the physical structure of a database and contains the names and locations of redo log files, the time stamp of the database creation, the current log sequence number, checkpoint information, and so on.
At the physical level, data files comprise one or more data blocks, where the block size can vary between data files. Data files can occupy pre-allocated space in the file system of a computer server, utilize raw disk directly, or exist within ASM logical volumes.
